Peterbilt 520
| Stock: 520 |
Detailed Specs
Peterbilt
520
Additional Information
8
LED Headlights, Halogen Headlights, Daytime Running Lights, LED Clearance Lights, LED Marker Lights, Fog Lights, Spotlights.
Up to 89k lbs.
320 - 430 hp
1,000 - 1,650 lb.-ft.
PACCAR MX-11
Configuration: Inline 6-Cylinder, Displacement: 10.8 L, Horsepower: Up to 430 hp, Peak Torque: Up to 1,650 lb.-ft. Base Warranty1: 2 years/250K MI/400K KM.
PACCAR PX-9
Configuration: Inline 6-Cylinder, Displacement: 8.9 L, Horsepower: Up to 380 hp, Peak Torque: Up to 1,250 lb.-ft. Base Warranty1: 2 years/250K MI/400K KM.
Cummins ISX12N
Configuration: Inline 6-Cylinder, Displacement: 11.9 L, Horsepower: Up to 350 hp, Peak Torque: Up to 1,450 lb.-ft. Base Warranty1: 2 years/250K MI/400K KM.
Cummins L9N
Configuration: Inline 6-Cylinder, Displacement: 8.9 L, Horsepower: 320 hp, Peak Torque: 1,000 lb.-ft. Base Warranty1: 2 years/250K MI/400K KM.
Allison 4000/4500/4700
Automatic, 3000 Series, 4000 Series, 4500 Series.
Eaton FR/RT
Manual 10/11/13 Speed.
12,000 - 20,000 lbs. PACCAR, Dana, Meritor.
21,000 - 78,000 lbs. Single, Tandem, Tridem, Dana, Meritor.
Peterbilt Air Trac, Peterbilt Air Leaf, Peterbilt Low Air Leaf, Hendrickson HMX EX, Neway ADZ, Reyco, Chalmers.
Up to 9” Extension, Aluminum, Steel, Polished, Painted, Chromed, Swept Back.
Peterbilt Driver, Peterbilt Pass, Sears C2 Plus Premium Driver, Adjustable RH Stand-up.
7” Digital Display, Tilt/Telescoping Steering Column.
https://www.peterbilt.com/static-assets/documents/resources/mx_engine_brochure.pdf
Description
The Model 520 is designed for demanding vocation industries like refuse, concrete pumping, paint striping and more. Features an updated VMUX electrical architecture and pre-configured frame layouts for easier integration with a variety of bodies. The Model 520 has a sturdy galvanized steel cab frame and a 90-degree door opening for convenient cab access. It offers options for right-hand drive, left-hand drive, right-hand stand-up and left-hand sit/right-hand stand-up configurations.
